AOI (Automatic Optical Inspection), also known as automatic optical inspection, relies on light to illuminate the target, the camera takes pictures to form a picture, and then completes the printed circuit board inspection through a series of algorithm comparisons, and outputs the results.

To evaluate the AOI method, the machine uses the internal lighting unit to decompose the solder and components into different colors. When making the inspection program, first take a standard board and set appropriate color parameters for the different parts of each component above.

During the inspection, the machine will take the captured image of the standard board as the standard image, and use the set color parameters as the standard. The image of the inspected substrate is compared with the standard image, and the judgment is made based on the set color parameters.

As the soul of AOI, our ideal hope light source should have the following points, multi-level, multi-angle, uniform light, stable light source, non-degradation, and long life. Of course, the actual AOI equipment can only be approached and cannot be fully realized.

Light source service life: First of all, the light can't keep on. This is an NG design of some equipment. Most of them have been improved and are not common. The light needs to be constantly on and off according to the requirements of the signal, and the intensity and stability of the light source must be ensured. It is best to have an independent power supply.

Shenzhen Panshi Group is a provider focusing on the research and development, production, sales and service of industrial automation and intelligent equipment, providing complete non-standard automation and solutions and services for various industries. The company’s main products cover semiconductor device testing, sorting, marking and taping integrated machines, sorting machines, testing machines and equipment for dispensing, laminating, assembly and other equipment, which are widely used in semiconductors, consumer electronics, glass cover plates, information communication and other sectors Group company.

The company is committed to exploring, integrating and applying cutting-edge technologies, adhering to customer needs as the center, pursuing the development philosophy of "cooperation, win-win, independence, and innovation", and adhere to the "technology-based enterprise, service-based enterprise, Word-of-mouth establishment of the enterprise” development concept, do a good job in technological innovation, product innovation, management innovation and service innovation, to help customers realize industrial automation of new processes and technologies, and at the same time achieve the goals of safe production, energy saving and emission reduction, and realize the ecological circle The win-win situation and the maximization of value.
